Multinomial logistic regression#
Let \(\mathcal Y\) be a finite set, e.g. \(\mathcal Y=\{1, 2, \ldots, K\}\), and the training dataset
\[
\mathcal D = \{(\boldsymbol x_i, y_i)\}_{i=1}^n, \quad \boldsymbol x_i\in\mathbb R^d, \quad y_i\in \mathcal Y.
\]
Multinomial logistic regression predicts a vector of probabilities
\[
\boldsymbol{\widehat y} = (p_1,\ldots, p_K), \quad p_k > 0, \quad \sum\limits_{k=1}^K p_k = 1.
\]
How to predict these probabilities? We can use a linear model whose output is a vector of \(K\) different numbers:
\[
z_k = \boldsymbol x^\top \boldsymbol w_k, \quad \boldsymbol w_k \in \mathbb R^d, \quad
k = 1, \ldots, K.
\]
Now convert the vector \(\boldsymbol z \in \mathbb R^K\) to the vector of probabilities \(\boldsymbol{\widehat y}\) via softmax:
\[
\boldsymbol{\widehat y} = \mathrm{Softmax}(\boldsymbol z) = \bigg(\frac{e^{z_1}}{\sum e^{z_k}}, \ldots, \frac{e^{z_K}}{\sum e^{z_k}}\bigg)
\]
If we need to pick a class, we can choose the most probable one:
\[
\arg\max\limits_{1\leqslant k \leqslant K} p_k =
\arg\max\limits_{1\leqslant k \leqslant K} \Big\{\frac{\exp(\boldsymbol x^\top \boldsymbol w_k)}{\sum \exp(\boldsymbol x^\top \boldsymbol w_k)}\Big\}
\]
The parameters \(\boldsymbol w_k\) naturally form a matrix
\[
\boldsymbol W = [\boldsymbol w_1 \ldots \boldsymbol w_K]
\]
Q. What is the shape of this matrix? How many parameters does multinomial regression have?
Loss function#
The optimal parameters \(\boldsymbol W\) are solutions of the following optimization problem:
(26)#\[\mathcal L (\boldsymbol W) = \sum\limits_{i=1}^n \bigg(\boldsymbol x_i^\top\boldsymbol w_{y_i} -\log\Big(\sum\limits_{k=1}^K \exp(\boldsymbol x_i^\top\boldsymbol w_{k})\Big)\bigg) \to \max\limits_{\boldsymbol w_{1}, \ldots, \boldsymbol w_{K}}\]
If the targets \(y_k\) are one-hot encoded, then they from a matrix
\[\begin{split}
\boldsymbol Y = \begin{pmatrix}
\boldsymbol y_1^\top \\
\vdots \\
\boldsymbol y_n^\top
\end{pmatrix},
\quad
y_{ik} \geqslant 0, \quad \sum\limits_{k=1}^K y_{ik} = 1.
\end{split}\]
Accordingly, the loss function (27) can be written as
(27)#\[\mathcal L (\boldsymbol W) = \sum\limits_{i=1}^n \sum\limits_{k=1}^K y_{ik}\log\bigg(\frac{\exp(\boldsymbol x_i^\top\boldsymbol w_k)}{\sum\limits_{1 \leqslant k \leqslant K}\exp(\boldsymbol x_i^\top\boldsymbol w_{k})}\bigg) = \sum\limits_{i=1}^n \sum\limits_{k=1}^K y_{ik} \log \widehat y_{ik},\]
and this is generally the cross-entropy loss (3), taken with opposite sign.
Question
Denote \(\boldsymbol{\widehat Y} = (\widehat y_{ik}) = \mathrm{Softmax}(\boldsymbol {XW})\) (softmax is applied to each row). Rewrite the loss function (27) in matrix form.
Answer
\[
\sum\limits_{i=1}^n \sum\limits_{k=1}^K y_{ik} \log \widehat y_{ik} = \mathrm{tr} (\boldsymbol Y^\top \boldsymbol {\widehat Y}).
\]
Regularized version:
\[
\sum\limits_{i=1}^n \Big(\boldsymbol x_i^\top\boldsymbol w_{y_i} -\sum\limits_{k=1}^K \exp(\boldsymbol x_i^\top\boldsymbol w_{k})\Big) - C\Vert \boldsymbol W \Vert_F^2 \to \max\limits_{\boldsymbol W}, \quad C > 0.
\]
Q. Why do we see minus before the regularization term?
Example: MNIST#
import numpy as np
import matplotlib.pyplot as plt
import seaborn as sns
from sklearn.metrics import accuracy_score, confusion_matrix
from sklearn.datasets import fetch_openml
from sklearn.linear_model import LogisticRegression
from sklearn.model_selection import train_test_split
%config InlineBackend.figure_format = 'svg'
X, Y = fetch_openml('mnist_784', return_X_y=True, parser='auto')
X = X.astype(float).values / 255
Y = Y.astype(int).values
---------------------------------------------------------------------------
ModuleNotFoundError Traceback (most recent call last)
Cell In[1], line 3
1 import numpy as np
2 import matplotlib.pyplot as plt
----> 3 import seaborn as sns
4 from sklearn.metrics import accuracy_score, confusion_matrix
5 from sklearn.datasets import fetch_openml
ModuleNotFoundError: No module named 'seaborn'
Visualize data#
Visualize some random samples:
---------------------------------------------------------------------------
NameError Traceback (most recent call last)
Cell In[2], line 19
16 plt.title(title, size=20)
17 plt.show()
---> 19 plot_digits(X, Y, random_state=12)
NameError: name 'X' is not defined
Splitting into train and test#
X_train, X_test, y_train, y_test = train_test_split(X, Y, test_size=10000)
X_train.shape, X_test.shape, y_train.shape, y_test.shape
---------------------------------------------------------------------------
NameError Traceback (most recent call last)
Cell In[3], line 1
----> 1 X_train, X_test, y_train, y_test = train_test_split(X, Y, test_size=10000)
2 X_train.shape, X_test.shape, y_train.shape, y_test.shape
NameError: name 'train_test_split' is not defined
Check that the classes are balanced:
np.unique(y_test, return_counts=True)
---------------------------------------------------------------------------
NameError Traceback (most recent call last)
Cell In[4], line 1
----> 1 np.unique(y_test, return_counts=True)
NameError: name 'y_test' is not defined
Fit and evaluate#
Fit the logistic regression:
%%time
LR = LogisticRegression(max_iter=100)
LR.fit(X_train, y_train)
---------------------------------------------------------------------------
NameError Traceback (most recent call last)
File <timed exec>:1
NameError: name 'LogisticRegression' is not defined
Make predictions:
y_hat = LR.predict(X_test)
y_hat
---------------------------------------------------------------------------
NameError Traceback (most recent call last)
Cell In[6], line 1
----> 1 y_hat = LR.predict(X_test)
2 y_hat
NameError: name 'LR' is not defined
We can also predict probabilities:
y_proba = LR.predict_proba(X_test)
y_proba[:3]
---------------------------------------------------------------------------
NameError Traceback (most recent call last)
Cell In[7], line 1
----> 1 y_proba = LR.predict_proba(X_test)
2 y_proba[:3]
NameError: name 'LR' is not defined
Calculate metrics:
print("Accuracy:", accuracy_score(y_test, y_hat))
---------------------------------------------------------------------------
NameError Traceback (most recent call last)
Cell In[8], line 1
----> 1 print("Accuracy:", accuracy_score(y_test, y_hat))
NameError: name 'accuracy_score' is not defined
Visualize performance#
plt.figure(figsize=(10, 8))
plt.title("Logistic regression on MNIST")
sns.heatmap(confusion_matrix(y_test, y_hat), annot=True);
---------------------------------------------------------------------------
NameError Traceback (most recent call last)
Cell In[9], line 3
1 plt.figure(figsize=(10, 8))
2 plt.title("Logistic regression on MNIST")
----> 3 sns.heatmap(confusion_matrix(y_test, y_hat), annot=True);
NameError: name 'sns' is not defined
Plot some samples with predictions and ground truths:
plot_digits(X_test, y_test, y_hat)
---------------------------------------------------------------------------
NameError Traceback (most recent call last)
Cell In[10], line 1
----> 1 plot_digits(X_test, y_test, y_hat)
NameError: name 'X_test' is not defined
